SIG. Hybrid 1002
2 Zone and 4 Zone Microprocessor Based Fire Alarm Control Panel
- SYSTEM AS PER IS-2189 : 1999 AND NFPA SPECIFICATIONS,
- ALL STATUS DISPLAYED ON LCD DURING STARTUP.
- AUTOMATIC ALL ZONE SCANNING AFTER 90 SEC.
- ZONE ISOLATION FACILITY VIA INTERNAL SOFTWARE.
- INTELLIGENT INBUILT BATTERY COMPARISON CHARGER.
- ADVANCE ZONE TESTING FACILITY.
- USER FRIENDLY
- BUZZER PRODUCES TWO DIFFERENT SOUNDS TO DIFFERENTIATE BETWEEN.
- FIRE ALARM CONDITIONS AND FAULT / WARNING CONDITIONS.
Download Datasheet
- CPU: 8 BIT ISP PROCESSOR BY BRAND NAME ATMEL
- AC SUPPLY: 230 VOLT
- SYSTEM OPERATING VOLTAGE: 24 VOLT .DC
- BATTERY: (7.2Ah)12 VOLT X 2 NOS.
- FUSE: AC 0.5 A, DC 1.5 A, BATT 3.0 A,
- CHARGING VOLTAGE: INTELLIGENT INBUILT COMPARISON 26.6 VOLT DC
- E.O.L: 4K.7 OHMS.
- OUTPUT RELAY CONTACT: FIRE C.NO.NC / FAULT C.NO.NC / COM HOOTER OUT
- CABINET DIMENSION: 2 - 4 - ZONE / H240XW350XD95 MM (H X W X D)
- CABLE ENTR: 20/25 MM 7 NOS. KNOCKOUT LOCATED AT THE TOP & BOTTOM AND REAR OF THE CABINET
